Performance And Characteristics

1.The machine are controlled by PLC program,The time between each action and action,and action residence time can be adjusted.And it also can be chose according to the product and the operation habit.

2.The material of the frame and the operation table is precision-machined and thicken.Equipped with precise chute in the frame and operation table.So that it can be adjusted the size,angle to meet the standard.The reverse clamp design makes the adjustment very convenient.

3.Position correction and pressing box are controlled by large diameter and small stroke cylinder,which does not only act quickly with high pressure but also save air source.

4.The action of auto press bubble and box outlet is consecutive and stable and safe.Production of the box is beautiful.No bubble and indentation in the surface.Produce capacity:10-20 pcs/min.

5.In the production of the box of different heights,put the box into the operation table,adjust the height by screw rising device and fixed.It can save time and easy contril the size of side of box.

6.In the production of the box of different sizes.it does not need to change the four sides press plates.It is standard equipped with five press plates which suit for adjustable range:min:100×100×10mm---max:350×350×120mm

7.There are thick paper(eg:200-350G gold and silver cards)anti rebound device options,the customer can choose the option item according to different box.

8.The machine adopt famous brand linear bearing.hard chrome plated shaff,the surfaee coated by the baking powder enamel printed etc.

Main Technical Parameters
